Tangential Fan Adjustable Speed 60mm Tangential Blower 230V 50HZ Mounting Direction Flexible
Specification:
| Motor Type | AC shaded pole motor YJ61-20 |
| Blower size | 60X240mm |
| Rated voltage/frequency | 230V 50HZ |
| Starting voltage | <= 176V |
| Rated current | <= 0.2A |
| Rated power | 27+/20% W |
| Rated speed | 2000+/- 10% RPM |
| Rising Temp. | IEC60335-1 |
| Lock Temp. | IEC60335-1 |
| High-voltage test | 1800VAC/2mA/1S |
| Cold insulation resistance | >= 100MΩ |
| End play | 1.0mm max |
The cross flow fan/tangential fan is generally made up of drive motors, blowers, shells, operating support connectors, etc. It is widely used in different field- hotel appliance, testing machines, home appliances,
It has the following features:
Low back pressure
Large flow
Low noise
Resist high temperature
Product design concept suitable for complete complanation.
Drawing:
Application: Air curtain, Air conditioning, Freezers, Electric Fireplaces, Oven
