Tangential Blower Fan Cross Flow Fan 60/65mm Blower Size 300mm Long 220-240V 50HZ
Specification:
| Motor Type | AC shaded pole motor YJ61-25 |
| Blower size | 60X300mm |
| Rated voltage/frequency | 230V 50HZ |
| Starting voltage | <= 176V |
| Rated current | <= 0.5A |
| Rated power | 40+/20% W |
| Rated speed | 2100+/- 10% RPM |
| Rising Temp. | IEC60335-1 |
| Lock Temp. | IEC60335-1 |
| High-voltage test | 1800VAC/2mA/1S |
| Cold insulation resistance | >= 100MΩ |
| End play | 1.0mm max |
Drawing:
Application: This kind of cross flow fan is widely used in different industries, like hotels, construction works, home use appliances and so on. For example, Air curtain, Air conditioning, Freezers, Electric Fireplaces, Oven, Heater fan.
