Oil-Free Air Compressor For Oxygen Concentrator 5L Use 220V 50HZ Optimum Life
Oilless air compressor features:
Oil-less operation(clean air stream, less maintenance)
Permanently lubricated ball bearing(optimum life)
Brass valves(optimum life, consistent performance, corrosion resistance)
High performance piston seal (optimum life)
Die-cast aluminum components(strong, lightweight, durable)
Thin wall, hard coated aluminum cylinder(maxium heat transfer)
Wetted parts treated for corrosion resistance
Dynamically balanced(low operation vibration)
Thermally protected motor
Pressure relief valve included
Twin fans provide cooling air for the motor and cylinders
Low noise
Continous duty
Specification:
| Model | Rated voltage/frequency V/HZ | Rated Speed RPM | Rated input power W | Working air pressure Kpa | Rated flow rate L/M |
| ZL300(5L) | 220V 50HZ | 1400RPM | 300W | 140Kpa | >70L/M |
| ZL300(5L) | 220V 60HZ | 1680RPM | 300W | 140Kpa | >70L/M |
| ZL300(5L) | 110V 50HZ | 1400RPM | 300W | 140Kpa | >70L/M |
| ZL300(5L) | 110V 60HZ | 1680RPM | 300W | 140Kpa | >70L/M |
Drawing:
Application: Often for Oxygen generator 5L
