Suction Machine 600mmhg Motor For Vacuum Pump 220v 50hz

2000pcs
MOQ
Suction Machine 600mmhg Motor For Vacuum Pump 220v 50hz
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Compressor Nebulizer Motor
Rated Voltage: 220V 50HZ
Stack Size: 62.5x62.5mm
Lamination: 40mm
Phase: Single Phase
Number Of Poles: Two
Insulation Class: CL.B
Bearing: Ball Bearing Or Sleeve Bearings Optional
Pump Nozzle: Direction Is Flexible
Rated Load: Atomizing Chamber
Time Rating: S1 (continuous)
Packing: Customized Packing
Printing: Customized Printing
Application: Compressor Nebulizer/Vacuum Use/Inhaler
High Light:

suction machine motor for vacuum pump

,

220v 50hz motor for vacuum pump

,

600mmhg small suction motors

Basic Infomation
Place of Origin: China
Brand Name: Zhaoli
Certification: UL, CUL, CE, VDE, CCC, ROHS, REACH
Model Number: YJ62-40
Payment & Shipping Terms
Packaging Details: cartons + wooden pallet
Delivery Time: 20-40 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 300,000pcs per day
Product Description

Pump Motor Vucumn Pump For Suction Machine 600mmHg 220V 50HZ





Specification:



Rated voltage/frequency V/HZ 220V 50HZ
Rated current A 0.90A max
Rated input power W 90W max
Max vacumn pressure ≥600mmHg
Rated flow rate L/H 18L/M
Noise Measured at 1 meter from pump at rated voltage rated speed, ≤ 70dB
Piston bearing Ball bearing
Insulation resistance The cold insulation resistance between stator and terminal shall be more than 100MΩ(tested by DC 500V megger)
Dielectric strength It shall be enough to withstand with application AC 1800V/2mA/1s. No puncture.
Life At rated load, 20 mins on, 40 mins off as one cycle. 2000 hours min.



Drawing:

Suction Machine 600mmhg Motor For Vacuum Pump 220v 50hz 0







Application:  Suction Machine, sputum aspirator
